| Signal Format | Analog |
|---|---|
| Style Name | Boom microphone stand with a telescoping boom arm |
| Color | Blue Headshell, White Cartridge |
| Item Weight | 0.05 kg |
| Enclosure Material | Stainless Steel |
| Model Name | OM Scratch |
| Unit Count | 1 Count |
| Manufacturer | Ortofon |
| Model Number | 8541736486 |
| Mfr Part Number | 0702991 |
| Warranty Description | 2-year warranty. |
| Price | — no data |
| Stylus Type | Spherical |
| Tracking Force | 4.0g |
| Output Voltage | 5 mV |
| Frequency Range | 20-18.000 Hz |
| Material | Stainless Steel |
| Style | Boom microphone stand with a telescoping boom arm |
| Number Of Packs | 1 |
The OM Scratch White on the SH-4 Black headshell is a practical and convenient solution for our customers who wish direct and easy mounting and replacement on their S-shaped tonearm.
Features: • Universal mount fitting a wide range of S-shaped tonearms • Correct Baerwald alignment with the major part of tonearms with universal mount • Spherical stylus minimizes scratching • Increased tracking ability • Reinforced rubber suspension
High output and maximum scratch performance!
Firstly lock the turntable tone arm, unscrew the cartridge, gently remove the stylus from the cartridge and insert a new stylus. A stylus is changed usually by pulling straight out and in the opposite direction of the turntable's arm. If the stylus doesn't come with directions, try these: with one hand, hold the cartridge to steady it. With the other hand, using a pair of tweezers, grasp the stylus from both sides and pull. Install the new stylus: holding the stylus from the top, press it gently into the space at the tip of the cartridge where the old stylus had been. Don't force it.
Cleaning of record by means of carbon fibre brush before and after every use. Cleaning of record by using record cleaning machine once in a while.
Cleaning of stylus by means of a fine antistatic brush. Please remember to remove dust from the diamond tip before and after playback of each record. Use the brush in the forward direction from the rear of the cartridge towards the stylus tip and never from stylus tip to the rear of the cartridge and never from side to side.
Proper adjustment of antiskating, azimuth and tracking force.
Ortofon's OM Series of DJ cartridges are available in two versions: Single or Pre-mounted.
The single version is just the cartridge and does NOT include a headshell.
The pre-mounted version includes a headshell and the cartridge is already mounted to it for easy installation.
